The distribution of household air switches, grasping the following elements is the key:
(1) Is the main switch of the home an air switch or a leakage protection?
The main switch is equipped with leakage protection, which is a way to save money, but in terms of influence, as long as the lamps and sockets in any of the following circuits leak electricity, the main switch will trip, and the impact is too great. The standard practice is to provide electrical protection for the common socket circuit, the cabinet air conditioner socket circuit and the bathroom lighting circuit, that is, the circuit below the distribution box should be set with leakage protection based on functional considerations. Although the cost of such an approach has increased, the safety and the impact of power outages have become smaller.
(2) How to distribute household sockets and switches
Distribution of sockets:
1. There are 2 sockets on the TV background wall in the living room, one on the left and right on the sofa background, and one on each other wall;
2. One for each wall in the dining room, generally around 2 to 3 in total (sometimes the refrigerator will be considered in the living room);
3. There are 2 sockets at the TV cabinet in the bedroom, one on the left and right of the bed background, and one on the wall by the window or balcony (if there is a desk in the bedroom, additional computer sockets should be considered);
4. There are about 4 to 5 kitchens;
5. 2 toilets.
Switch control:
1.The switches in the living room, dining room, and aisle are centrally installed for one control (if the aisle is long, it is better to control both ends);
2. Room control switch;
3. Kitchen single switch;
4. Single-connection switch in the bathroom (repurchased by Yuba);
5. Balcony single switch;
Circuit distribution:
1. Aisle, living room, dining room lighting 1 circuit;
2. All bedrooms (within 3 bedrooms), balcony lighting 1 circuit;
3. Kitchen and bathroom lighting 1 circuit (consider Yuba power);
4. Living room, dining room, aisle socket 1 circuit;
5. 1 circuit of kitchen and bathroom sockets (considering that kitchen appliances are relatively concentrated, if conditions permit, consider a separate circuit in the kitchen);
6. Bedroom (below 2 bedrooms), balcony socket 1 circuit;
7. Each air conditioner has 1 circuit;
(3) The grouping after that, is it grouped by purpose or by region?
You can group by purpose. All lighting uses air switches, and the air switches of multiple sockets share a leakage protection, which is economical and safe. Air conditioners, refrigerators, kitchen appliances, and bathroom heaters are all separate, and there is a separate room for lighting after a total switch.
Distinguish by function, namely: lighting, ordinary sockets, toilet sockets, air conditioning sockets
(4) When installing concealed wires, is it better to use single-core wires or multi-strand wires?
If you install dark wire, it is better to use single core wire.
